DESCRIPTION |
UNITS |
CSS 500 |
CSS 600 |
CSS 700 |
CSS 900 |
||
|
Lifting Capacity |
ton-meter |
42.0 |
45.0 |
55.7 |
64.0 |
||
|
Lifting Capacity / Outreach |
kg/m |
14700 / 2.0 |
14200 / 2.0 |
19000 / 2.0 |
21000 / 2.0 |
||
|
8000 / 5.3 |
7170 / 6.0 |
9280 / 6.0 |
8610 / 7.0 |
||||
|
4720 / 8.0 |
3590 / 10.0 |
4720 / 10.0 |
4180 / 11.6 |
||||
|
2330 / 15.0 |
2140 / 15.0 |
2780 / 15.0 |
2710 / 16.2 |
||||
|
1600 / 20.0 |
1000 / 25.2 |
1050 / 27.0 |
1050 / 30.0 |
||||
|
Working Radius |
m |
20.0 |
25.2 |
27.0 |
30.0 |
||
|
Max. Working Height |
m |
22.8 |
28.0 |
29.8 |
33.0 |
||
|
Rated Oil Flow, Recommended |
งค / min |
88 / 88 |
|||||
|
Working Pressure |
kg / cm² |
200 |
220 |
210 |
195 |
||
|
Oil Tank Capacity |
งค |
200 |
250 |
||||
|
Shape Of Boom |
|
Hexagonal box construction, 5 sections |
Hexagonal box construction, 6 sections |
Hexagonal box construction, 6 sections |
Hexagonal box construcion, |
||
|
Boom Length |
m |
Min. 5.6, |
Min. 6.3, |
Min. 6.8, |
Min. 7.53, |
||
|
Boom Extending Speed |
m / sec |
14.4 / 35 |
19.2 / 60 |
20.5 / 60 |
23.0 / 65 |
||
|
Boom Raising Speed |
° / sec |
0~80 / 25 |
-10~80 / 30 |
-9~80 / 30 |
|||
|
Slewing Angle |
° |
360° continuous |
|||||
|
Slewing Speed |
r.p.m. |
1.5 |
1.0 |
1.0 |
|||
|
Wire Rope |
Ø X m |
14.0 X 100 |
14.0 X 120 |
16.0 X 120 |
|||
|
Hook Speed |
m / min |
15 (4 fall lines) |
100/50 (1fall line) |
100/60 (1fall line) |
|||
|
Winch Type |
|
Hyd, Motor driven, spur gear speed reduction with hydraulic brake |
2 speed winch hydraulic motor driven Planetary gear reduction hydraulic brake system |
||||
|
Single Line Pull |
ton |
3.0 |
3.5 |
||||
|
Slewing Reduction Gear Type |
|
Hyd, Motor driven, combined type of planetary gear and |
|||||
|
Outrigger Span, Main |
Ext |
m |
6.11 |
6.91 |
7.11 |
||
|
Ret |
m |
2.29 |
|||||
|
Truck chassis, Recommended |
GVW(ton) |
30 |
39 |
||||
|
Optional feature |
(1) Rear outrigger system (2) Additional winch system of 2.5 ton and 3.0 ton (3) Additional manual Jib Boom of 4.0 meters or more (4) Personal Basket (5) Top Seat Control (6) Several options if customers request for their comfortable and safe work (7) Hydraulic Pump |
||||||
CSS 500
CSS 600
CSS 700
CSS 900
|
CSS900 TYPE RATED LOADS |
||||||||||||||||
| BOOM RADIUS (m) |
2.0 |
3.0 |
4.0 |
5.0 |
6.0 |
10.0 |
12.0 |
14.0 |
16.0 |
18.0 |
20.0 |
22.0 |
24.0 |
26.0 |
28.0 |
30.0 |
|
|
21000 |
16000 |
13360 |
11650 |
10400 |
8610 |
|
|
|
|
|
|
|
|
|
|
|
|
|
13100 |
10570 |
8920 |
7780 |
5270 |
4180 |
|
|
|
|
|
|
|
|
|
|
|
|
12300 |
9810 |
8170 |
7040 |
4640 |
4000 |
3500 |
2710 |
|
|
|
|
|
|
|
|
|
|
|
9400 |
7770 |
6660 |
4280 |
3650 |
3190 |
2830 |
2560 |
1920 |
|
|
|
|
|
|
|
|
|
|
5000 |
5000 |
4030 |
3410 |
2970 |
2610 |
2340 |
2110 |
1910 |
1710 |
1400 |
|
|
|
|
|
|
|
5000 |
5000 |
3780 |
3240 |
2800 |
2450 |
2180 |
1960 |
1780 |
1540 |
1470 |
1330 |
1050 |
|
CSS700 TYPE RATED LOADS |
||||||||||||||||
| BOOM RADIUS (m) |
2.0 |
3.0 |
4.0 |
5.0 |
6.0 |
10.0 |
12.0 |
14.0 |
15.0 |
18.0 |
20.0 |
21.0 |
23.0 |
24.0 |
26.0 |
27.0 |
|
|
19000 |
15100 |
12340 |
10670 |
9280 |
7930 |
|
|
|
|
|
|
|
|
|
|
|
|
15890 |
12380 |
9800 |
8260 |
7240 |
4720 |
3960 |
|
|
|
|
|
|
|
|
|
|
|
|
11280 |
8910 |
8120 |
6500 |
4380 |
3690 |
3100 |
2600 |
|
|
|
|
|
|
|
|
|
|
11400 |
8570 |
6800 |
6180 |
3930 |
3400 |
2940 |
2780 |
2230 |
1860 |
|
|
|
|
|
|
|
|
|
|
5000 |
5000 |
3640 |
3100 |
2750 |
2600 |
2170 |
1940 |
1810 |
1390 (22.8M) |
|
|
|
|
|
|
|
|
|
5000 |
3420 |
2970 |
2660 |
2400 |
2000 |
1800 |
1750 |
1570 |
1490 |
1290 |
1050 |
|
CSS600 TYPE RATED LOADS |
||||||||||||||||
| BOOM RADIUS (m) |
2.0 |
3.0 |
4.0 |
5.0 |
6.0 |
10.0 |
12.0 |
14.0 |
15.0 |
18.0 |
20.0 |
21.0 |
22.0 |
23.0 |
24.0 |
25.0 |
|
|
14200 |
11100 |
9730 |
8460 |
7170 |
|
|
|
|
|
|
|
|
|
|
|
|
|
12300 |
9430 |
7500 |
6400 |
5540 |
3590 |
|
|
|
|
|
|
|
|
|
|
|
|
9880 |
8860 |
6910 |
5750 |
4980 |
3320 |
2860 |
2370 |
|
|
|
|
|
|
|
|
|
|
|
|
5000 |
5000 |
4660 |
3020 |
2590 |
2270 |
2140 |
1710 |
|
|
|
|
|
|
|
|
|
|
|
5000 |
4460 |
2830 |
2400 |
2090 |
1960 |
1670 |
1500 |
1390 |
1280 |
|
|
|
|
|
|
|
|
|
4310 |
2740 |
2260 |
1960 |
1830 |
1540 |
1390 |
1320 |
1260 |
1200 |
1140 |
1000 |
|
CSS500 TYPE RATED LOADS |
||||||||||||||||
|
BOOM RADIUS (m) |
2.0 |
3.0 |
4.0 |
5.0 |
6.0 |
9.0 |
13.0 |
14.0 |
15.0 |
17.0 |
19.0 |
20.0 |
21.0 |
22.0 |
23.0 |
24.0 |
|
|
14700 |
11420 |
9680 |
8510 |
7780 |
|
|
|
|
|
|
|
|
|
|
|
|
|
12440 |
9250 |
7500 |
6450 |
5710 |
4110 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
6830 |
5750 |
5020 |
3760 |
2770 |
|
|
|
|
|
|
|
|
|
|
|
|
|
5000 |
5000 |
4700 |
3410 |
2610 |
2460 |
2330 |
2050 |
|
|
|
|
|
|
|
|
|
|
5000 |
4950 |
4400 |
3130 |
2390 |
2130 |
1940 |
1760 |
1600 |
|
|
|
|
|
