DESCRIPTION |
UNITS |
CSS 103 |
CSS 104 |
CSS 105 |
CSS 106 |
CSS 107 |
|
|
Lifting Capacity |
ton-meter |
16.8 |
16.5 |
16.3 |
16.0 |
14.3 |
|
|
Lifting Capacity / Outreach |
kg/m |
7000/2.0 |
7000/2.0 |
7000/2.0 |
7000/2.0 |
6700/2.0 |
|
|
2580/6.0 |
2490/6.0 |
2440/6.0 |
2340/6.0 |
2170/6.0 |
|||
|
1670/9.0 |
1110/12.0 |
1070/12.0 |
1000/12.0 |
890/12.0 |
|||
|
1260/9.9 |
840/12.8 |
600/15.8 |
400/18.8 |
200/22.0 |
|||
|
Working Radius |
m |
9.9 |
12.8 |
15.8 |
18.8 |
22.0 |
|
|
Max. Working Height |
m |
12.7 |
15.6 |
18.6 |
21.6 |
25.8 |
|
|
Rated Oil Flow, Recommended |
งค / min |
63 |
|||||
|
Working Pressure |
kg / cm² |
200 |
|||||
|
Oil Tank Capacity |
งค |
145 |
|||||
|
Shape Of Boom |
|
Hexagonal box construction, 3 sections |
Hexagonal box construction, 4 sections |
Hexagonal box construction, 5 sections |
Hexagonal box construcion, |
Hexagonal box construction, |
|
|
Boom Length |
m |
Min. 4.4, Max. 10.1 |
Min. 4.5, |
Min. 4.6, Max. 16.0 |
Min. 4.7, |
Min. 4.8, |
|
|
Boom Extending Speed |
m / sec |
5.70 / 15 |
8.55 / 20 |
11.40 / 20 |
14.25 / 30 |
17.46 / 35 |
|
|
Boom Raising Speed |
° / sec |
0~78 /10 |
|||||
|
Slewing Angle |
° |
360° continuous |
|||||
|
Slewing Speed |
r.p.m. |
2.0 |
|||||
|
Wire Rope |
Ø X m |
10 X 80 |
10 X 80 |
10 X 100 |
10 X 100 |
10 X 100 |
|
|
Hook Speed |
m / min |
15 (4 fall lines) |
|||||
|
Winch Type |
|
Hyd, Motor driven, spur gear speed reduction with mechanical brake |
|||||
|
Single Line Pull |
ton |
1.5 |
|||||
|
Slewing Reduction Gear Type |
|
Hyd, Motor driven, worm gear speed reduction with hydraulic brake |
|||||
|
Outrigger Span, Main |
Ext |
m |
5.53 |
||||
|
Ret |
m |
2.06 |
|||||
|
Truck chassis, Recommended |
GVW(ton) |
10 |
10 |
15 |
15 |
15 |
|
|
Optional feature |
(1) Rear outrigger system (2) Additional winch system of 1.5 ton (3) Additional manual Jib Boom of 3.0 meters or more (4) Personal Basket (5) Top Seat Control (6) Several options if customers request for their comfortable and safe work (7) Hydraulic Pump |
||||||
CSS 103
CSS 104
CSS 105
CSS 106
CSS 107
|
CSS107 TYPE RATED LOADS |
|||||||||||||||||
| BOOM RADIUS (m) |
2.0 |
4.0 |
5.0 |
7.0 |
8.0 |
10.0 |
11.0 |
12.0 |
13.0 |
14.0 |
15.0 |
16.0 |
17.0 |
19.0 |
20.0 |
21.0 |
22.0 |
|
|
6700 |
3880 |
2970 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5200 |
3070 |
2520 |
1800 |
1380 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4600 |
2830 |
2330 |
1600 |
1490 |
1110 |
880 |
|
|
|
|
|
|
|
|
|
|
|
|
|
2760 |
2240 |
1600 |
1400 |
1110 |
1000 |
890 |
730 |
580 |
|
|
|
|
|
|
|
|
|
|
2550 |
2190 |
1540 |
1340 |
1040 |
980 |
870 |
780 |
700 |
620 |
590 |
410 |
|
|
|
|
|
|
|
2320 |
2020 |
1480 |
1260 |
1010 |
910 |
820 |
750 |
680 |
620 |
570 |
510 |
350 |
280 |
|
|
|
|
|
|
1980 |
1390 |
1240 |
960 |
890 |
780 |
720 |
650 |
590 |
540 |
510 |
420 |
370 |
330 |
200 |
(kg)
(kg)
(kg)
(kg)
|
CSS106 TYPE RATED LOADS |
|||||||||||||||||
| BOOM RADIUS (m) | 2.0 | 4.0 | 5.0 | 6.0 | 7.0 | 8.0 | 9.0 | 10.0 | 11.0 | 12.0 | 13.0 | 14.0 | 15.0 | 16.0 | 17.0 | 18.0 | 19.0 |
|
|
7000 | 3970 | 3020 (4.5m) |
||||||||||||||
|
|
5180 | 3310 | 2730 | 2340 | 1810 | 1510 (7.4m) |
|||||||||||
|
|
4930 (2.3m) |
3070 | 2540 | 2170 | 1880 | 1660 | 1450 | 1190 | 990 (10.2m) |
||||||||
|
|
2400 | 2370 | 2040 | 1780 | 1580 | 1410 | 1270 | 1130 | 1000 | 790 | 710 (13.1m) |
||||||
|
|
2400 | 2300 | 1970 | 1710 | 1510 | 1340 | 1200 | 1100 | 1000 | 890 | 830 | 730 | 520 (15.9m) |
||||
|
|
2250 | 1920 | 1640 | 1440 | 1290 | 1160 | 1050 | 960 | 890 | 830 | 750 | 680 | 620 | 540 | 400 (18.8m) |
||
|
CSS105 TYPE RATED LOADS |
|||||||||||||||||
| BOOM RADIUS (m) |
2.0 |
4.0 |
5.0 |
6.0 |
7.0 |
8.0 |
9.0 |
10.0 |
11.0 |
12.0 |
13.0 |
14.0 |
15.0 |
16.0 |
17.0 |
18.0 |
19.0 |
|
|
7000 |
4060 |
3160 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
6100 |
3450 |
2870 |
2440 |
2000 |
1630 |
|
|
|
|
|
|
|
|
|
|
|
|
|
5000 |
3170 |
2610 |
2250 |
1980 |
1730 |
1530 |
1220 |
1080 |
|
|
|
|
|
|
|
|
|
|
|
2400 |
2400 |
2130 |
1850 |
1640 |
1460 |
1330 |
1210 |
1070 |
780 |
|
|
|
|
|
|
|
|
|
2400 |
2320 |
2040 |
1760 |
1560 |
1410 |
1260 |
1160 |
1060 |
970 |
880 |
790 |
600 |
|
|
|
|
CSS104 TYPE RATED LOADS |
|||||||||||||||||
| BOOM RADIUS (m) | 2.0 | 4.0 | 5.0 | 6.0 | 7.0 | 8.0 | 9.0 | 10.0 | 11.0 | 12.0 | 13.0 | 14.0 | 15.0 | 16.0 | 17.0 | 18.0 | 19.0 |
|
|
7000 | 4070 | 3310 (4.3m) |
||||||||||||||
|
|
6200 | 3500 | 2940 | 2490 | 1970 | 1720 (7.1m) |
|||||||||||
|
|
2400 | 2400 | 2400 | 2290 | 2030 | 1790 | 1590 | 1150 | |||||||||
|
|
2400 | 2400 | 2170 | 1890 | 1700 | 1520 | 1380 | 1240 | 1110 | 840 (12.8m) |
|||||||
|
CSS103 TYPE RATED LOADS |
||||||||
| BOOM RADIUS (m) |
2.0 |
4.0 |
5.0 |
6.0 |
7.0 |
8.0 |
9.0 |
10.0 |
|
|
7000 |
4110 |
3480 |
|
|
|
|
|
|
|
6100 |
3600 |
3050 |
2580 |
2020 |
1870 |
|
|
|
|
|
3330 |
2770 |
2410 |
1850 |
1900 |
1670 |
1260 |
